Details:

* Features:

8 channels with mono input, each channel has 3 EQ+MF.

High-performance microphone amplifier with phantom power (+48V).

6 buses (stereo + group 4), 3 AUX for sending, 1 stereo for returning.

9 bands stereo EQ adjustment with level display light.

60mm slide-fader.

Built-in mute switching mode power supply.

Adjustable Sub output of 24-400Hz

Built-in DSP ( 99 sets of effects) and showed by screen.

Built-in MP3, Bluetooth receiver, SD card and USB input, automatically identify and play MP3 music.

SMT automated technique to achieve more stable and reliable performance.

Suitable for stages, pubs, KTV rooms and large conference rooms.

*Technical Parameters

Frequency Response:20Hz-20KHz ±0.5dB

THD+N: -30dB input to mix, mic gain 30dB,<0.007%

Mic Input Ein: MIC EIN@Max gain,150 ohms source impedance -128dB

Bus Noise: Noise(20Hz-20KHz measurement bandwidth)

Audio Mixing:MIX@MAX faders down<-85dB)

Crosstalk Between Channels:>96dB

Crossover Fader Position:>96dB

Aux Send Port:>86dB

Output Level Meter: L/R mix output level is 12 segment of LED indicator

Power: AC input 100-240V 50/60Hz

Power Consumption:<30W
